Description
Turtle AV TAV-CHAZY-CTL Overview
The CHAZY Advanced Control & Central Management Box from Turtle AV provides seamless routing and management over IP via any web browser. The unit features built-in Dante AV-A control and is equipped with dual 1G network ports. Boasting an intuitive WebGUI and true multicast support, the CHAZY offers advanced video wall management with API integration for systems like Q-SYS and Crestron. Crafted in a sleek, aqua-colored metal enclosure, the TAA-compliant device supports AES-256 video encryption and can be powered via a 12 VDC power option or via PoE (Power over Ethernet).
Control Overview
Embedding Dante Controller directly into the hardware for seamless routing and management over IP, the CHAZY features an intuitive WebGUI, true multicast support, and advanced features like video wall configurations up to 9x9, KVM, and API integration for systems like Q-SYS and Crestron. With dual network ports to keep AV and control separate, the device also has robust security features including HTTPS and SSH as well as AES-256 encryption. AV professionals can manage and route video and audio streams directly from any web browser on a laptop, desktop, tablet, or smartphone. No additional software installations are required, and the device has no internal fans, offering silent and vibration-free operation.
API Support & Automated Dante Routing
Whatever your control platform of choice may be among options like Q-SYS, Crestron, and Control4, the CHAZY's API allows you to program automated switching and routing for your Dante network.
Drag & Drop Interface
Routing signals has never been easier. Built directly into the WebGUI is an intuitive drag and drop interface, you can quickly and easily route one to one or one to many.
Security
HTTPS and SSH offers login peace of mind, with AES-256 encryption making the video and audio streams totally secure.
TAA Compliant
The CHAZY is TAA compliant, meeting U.S. government standards for procurement. This ensures that it can be confidently used in federal contracts, adhering to strict ethical sourcing and manufacturing regulations.
Items Included
- Turtle AV CHAZY Advanced Control & Central Management Box
- Power Supply
- Limited 5-Year Manufacturer Warranty
Additional Resources
No additional resources available
Turtle AV TAV-CHAZY-CTL Specs
Inputs/Outputs
| Ports |
1 x RJ45 LAN (Supports Video Input and PoE)
1 x RJ45 LAN (Control) 1 x 1/8" / 3.5 mm (IR Input) 1 x 1/8" / 3.5 mm (IR Output) 1 x 6-Pin Phoenix Connector (Digital Input/Output) 2 x 3-Pin Phoenix Connector (RS-232 Input/Output) 1 x Micro-USB (Upgrade) |
Power
| Power Source |
AC Input, PoE
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| DC Input Power |
12 VDC at 2.5 A
|
| Power Consumption |
2 W
|
Physical
| Color |
Aqua Blue
|
| Material of Construction |
Metal
|
| Operating Conditions |
32 to 104?F / 0 to 40?C at 20 to 90% Humidity
|
| Dimensions |
8 x 3.9 x 0.8" / 204 x 98.5 x 21.5 mm
|
| Weight |
1.1 lb / 508 g
|
Packaging Info
| Package Weight |
2.06 lb
|
| Box Dimensions (LxWxH) |
10.5 x 6.4 x 3"
|
