Description
TEKVOX SCU21T-KVM Overview
Versatile Video Output
The
SCU21T-KVM 4K 2x1 HDMI/USB-C HDBaseT Switcher Set from
TEKVOX provides versatile video switching and extension using one HDMI and one USB-C input and simultaneous HDMI and HDBaseT output. It supports up to UHD 4K60 4:4:4 HDR10 video with automatic switching, flexible control options, 48V PoC, and USB-C 60W device charging.
Simultaneous HDMI and HDBaseT Output
Transmit UHD 4K 60 video, audio, RS-232 control, Ethernet LAN, bidirectional 48V PoC (power over cable), and USB camera and mike feeds at distances up to 330' via HDBaseT. Simultaneous HDMI and HDBaseT outputs let you feed video to multiple displays in your videoconferencing setups.
USB Device Support
The SCU21T-KVM lets users access USB devices like touchscreens that are connected to the switcher or receiver and provides up to 60W USB-C charging for your connected components.
Auto Switching
Automatic source detection and switching keeps your viewers in the loop.
Control Options
The SCU21T-KVM provides RS-232, CEC (HDMI), and front-panel button control options.
Items Included
- TEKVOX SCU21T-KVM 4K 2x1 HDMI/USB-C HDBaseT Switcher Set
- Receiver
- Power Supply (100-240 VAC)
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
TEKVOX SCU21T-KVM Specs
Processing
| Color Processing |
4:4:4
4:2:0 |
Input
| Video Inputs |
1x HDMI (2.0b) Female
1x USB-C Female |
| Input Video Format |
HDMI (4:4:4)
UHD 4K up to 60 fps USB-C (4:4:4) UHD 4K up to 60 fps |
| Embedded Audio Input |
HDMI
USB-C |
Output
| Video Outputs |
1x RJ45 (HDBaseT) Female
1x HDMI (2.0b) Female |
| Output Video Format |
RJ45
UHD 4K up to 60 fps |
| Audio Outputs |
1x Block 5-Pin Stereo Analog Female
|
| Output Audio Format |
LPCM (Linear Pulse-Code Modulation)
|
| Embedded Audio Output |
RJ45
HDMI |
Connectivity
| Other I/O |
1x DIP Switch 4-Pin
2x USB-A Control 1x RJ45 LAN 1x Micro-USB Firmware 1x USB-B 2x Block 3-Pin Unspecified 2x Block 3-Pin RS-232 1x RJ45 |
| Digital Audio Decoding |
DTS-HD Master Audio, Dolby Digital Plus, Dolby Atmos, DTS:X, LPCM, Dolby TrueHD
|
| HDCP Support |
Yes: Version 2.2
|
| HDR Support |
Yes: HDR10
|
| DTS Compatibility |
DTS-HD Master Audio, DTS:X
|
| Dolby Compatibility |
Dolby Atmos, Dolby Digital Plus, Dolby TrueHD
|
IP Encoding/Decoding
| IP Video |
3840 x 2160 at 60p Encoding
|
| IP Audio |
Encoding
|
| Transport Protocols |
TCP/IP
|
| Simultaneous Streams |
1 Streams
|
Hardware
| Wireless |
No
|
Power
| Power I/O |
1x DIN 4-Pin (24 VDC at 1 A) Input/Output
1x USB-C Output |
| Power Consumption |
76.5 W
|
General
| Operating Conditions |
41 to 131?F / 5 to 55?C at 10 to 90% Humidity
|
| Dimensions |
10.1 x 5.9 x 1.3" / 256 x 150 x 32 mm
|
| Weight |
2.25 lb / 1.02 kg
|
