Description
Comprehensive CSW-C4000MC Overview
Connect and seamlessly switch between two USB cameras and a single HDMI source using the Pro AV/IT Integrator Series 3x1 Seamless USB Camera & HDMI Switcher from Comprehensive. Ideal for classrooms, auditoriums, houses of worship, and corporate video conferencing, the unit can also take in video signals originating from a document reader, a PTZ camera, or a local computer source. Audio I/O and mixing are available via the affiliated web interface, and control is supported using IP, RS-232, or third-party devices.
A USB-C output provides direct connectivity to any computer with the appropriate port, while an HDMI output may be used to send your output to a projector or other type of display. Powering is made possible via the included 12V, 1A power adapter or via PoE (Power over Ethernet) with an optional Ethernet cable connected to the integrated LAN/PoE port.
- HDMI input can be any HDMI source, such as a laptop, document camera, or PTZ camera
- Seamless switching among three input sources
- Mixed layout can be defined in the WebGUI: Picture-in-picture, side-by-side, big-and-small
- HDMI 2.0 output for local monitor and USB-C (UVC/UAC) output for computer connectivity
- Enable mute video/audio to video conferencing or live broadcasting
- Audio I/O and mixer through the web Interface
- Controllable via IP, RS-232, or third-party devices
- PoE (Power over Ethernet) supported
- Compact and slim housing design
Items Included
- Comprehensive Pro AV/IT Integrator Series 3x1 Seamless USB Camera & HDMI Switcher
- Power Adapter (12V, 1.5A)
- 4-Pin Phoenix Male Connector
- 4 x Screw
- 2 x Mounting Ear
- Limited 3-Year Manufacturer Warranty
Additional Resources
Comprehensive CSW-C4000MC Specs
| Switching Type |
Pushbutton, Software
|
| Processing Resolution |
UHD 4K at 30/60
|
| Video Inputs |
1x HDMI (1.4, 2.0) Female
1x USB-A (2.0, UVC) Female 1x USB-A (3.0, UVC) Female |
| Input Video Format |
HDMI
1080p at 60 fps 720p at 60 fps USB-A 1080p at 30 fps 720p at 30 fps |
| Audio Inputs |
1x 1/8" / 3.5 mm TRS Stereo Analog Female
|
| Input Audio Format |
Analog
LPCM (Linear Pulse-Code Modulation) |
| Embedded Audio Input |
HDMI
USB-A |
| Video Outputs |
1x HDMI (2.0) Female
1x USB-C (USB Video) Female |
| Output Video Format |
HDMI
UHD 4K at 30/60 fps 1080p at 60 fps 720p at 60 fps USB-C 1080p at 30 fps 720p at 30 fps |
| Audio Outputs |
1x 1/8" / 3.5 mm TRS Stereo Analog Female
|
| Output Audio Format |
Analog
LPCM (Linear Pulse-Code Modulation) |
| Embedded Audio Output |
HDMI
USB-C |
| Multiview Output |
3-Way Multiview via HDMI
|
| Other I/O |
1x Block 4-Pin RS-232 Input/Output
1x USB-A Firmware Input 1x RJ45 LAN, PoE Input/Output |
| Digital Audio Decoding |
LPCM
|
| HDCP Support |
Yes, Version 1.4/2.2
|
| HDR Support |
No
|
| Wireless |
No
|
| Power I/O |
1x Barrel (12 VDC at 1.5 A) Input
|
| Power Consumption |
15 W
|
| Operating Conditions |
32 to 113°F / 0 to 45°C at 20 to 85% Humidity
|
| Storage Conditions |
32 to 140°F / 0 to 60°C
|
| Dimensions |
7.1 x 3.7 x 0.7" / 180 x 95 x 18 mm
|
| Weight |
2.2 lb / 1 kg
|
| Package Weight |
1.935 lb
|
| Box Dimensions (LxWxH) |
10.4 x 8.4 x 2.6"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
