Description
BZBGEAR MVS4X4-4KL Overview
Effortless Setup Video Wall and Seamless 4x4 Matrix Switcher - BG-MVS4X4-4KL
SETUP and DEMO Video Wall and Seamless Matrix Switcher | BG-MVS4x4-4KL
The 4x4 UHD 4K HDMI Video Wall Processor & Seamless Matrix Switcher/Scaler from BZBGear is equipped with four HDMI inputs and four HDMI outputs to allow all input sources to be displayed simultaneously in 4x4, 2x2, 4x1, or 1x4 matrices. With these multiview layout options, this device is great for environments like video walls, digital advertising, conference rooms, industrial workstations, and surveillance monitoring.
Compliant with HDMI 1.3a and HDCP 1.2, this multiviewer supports output resolutions up to DCI/UHD 4K60. It features upscaling and downscaling, which allow sources of different resolutions to display without conflict. Control options include the front-panel buttons, TCP/IP, IR remote control, or RS-232 control.
Features
- HDMI 2.0b, HDCP 2.2, and HDCP 1.4 compliant
- Two operational modes: 4x4 Matrix (seamless switch) and video wall (2x2, 4x1, or 1x4 configuration)
- Audio format support for LPCM, DD, DD+, DTS, Dolby TrueHD, DTS HD-master passthrough
- Advanced EDID management for seamless communication between sources and displays
- Web interface for control and configuration of matrix
- Control via front panel, IR, RS-232, and TCP/IP
- Seamless video switching
- Video inputs support all industry-standard video resolutions including VGA to WUXGA (up to 1920 x 1200 at 60 Hz) and 480i to 4K (3840 x 2160p60 4:4:4, 4096 x 2160p60 4:4:4)
- HDMI outputs support upscale or downscale to any resolution, up to 4096 x 2160p60 4:4:4
- Third-party drivers are available for all major home control brands
UPC: 850050134473
Items Included
- BZBGEAR 4x4 UHD 4K HDMI Video Wall Processor & Seamless Matrix Switcher/Scaler
- 12 VDC Power Supply
- Remote Control
- 3-Pin Terminal Connector
- IR Receiver Cable (4.9')
- 2 x Mounting Ear
- 4 x Screw
- Limited 3-Year Manufacturer Warranty
Additional Resources
BZBGEAR MVS4X4-4KL Specs
Processing
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
UHD 4K at 60
|
| Color Processing |
8-Bit 4:4:4 YCbCr
8-Bit 4:2:2 YCbCr 8-Bit 4:2:0 YCbCr |
Input
| Video Inputs |
4x HDMI (2.0b) Female
|
| Input Video Format |
HDMI (8-Bit 4:4:4/4:2:2/4:2:0)
DCI 4K up to 60 fps UHD 4K up to 60 fps 1080p up to 60 fps WUXGA (1920 x 1200) up to 60 fps |
| Embedded Audio Input |
HDMI: 8-Channel (per Input)
|
Output
| Video Outputs |
4x HDMI (2.0b) Female
|
| Output Video Format |
HDMI (8-Bit 4:4:4/4:2:2/4:2:0)
DCI 4K at 50/60 fps UHD 4K at 30/50/60 fps 1080p at 30/50/60 fps 1080i at 50/60 fps WUXGA (1920 x 1200) at 60 fps 1360 x 768 at 60 fps WXGA (1280 x 800) at 60 fps 1280 x 720 (Non-Standard WXGA) at 60 fps XGA (1024 x 768) at 60 fps |
| Embedded Audio Output |
HDMI: 8-Channel (per Output)
|
| Multiview Output |
4-Way Multiview via HDMI
|
Connectivity
| Other I/O |
1x Block 3-Pin Control, RS-232 Input/Output
1x 1/8" / 3.5 mm IR Input 1x RJ45 LAN Input/Output |
| Digital Audio Decoding |
DTS-HD Master Audio, Dolby Digital Plus, Dolby Digital / AC3, DTS, DTS-HD High Resolution, DTS Express, Dolby TrueHD
|
| HDCP Support |
Yes, Version 2.2
|
| HDR Support |
Yes
|
| DTS Compatibility |
DTS, DTS Express, DTS-HD High Resolution, DTS-HD Master Audio
|
| Dolby Compatibility |
Dolby Digital, Dolby Digital Plus, Dolby TrueHD
|
Hardware
| Wireless |
Bluetooth / Wi-Fi
|
Power
| Power I/O |
1x Barrel (100 to 240 VAC ) Input
1x Barrel (12 VDC at 2.5 A) Output |
| Power Consumption |
19.56 W
|
General
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 90% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C at 20 to 90% Humidity
|
| Certifications |
CE, FCC, UL
|
| Rack Form Factor |
1 U
|
| Dimensions |
11 x 6.5 x 1.2" / 27.9 x 16.5 x 3 cm
|
| Weight |
2.6 lb / 1179 g
|
Packaging Info
| Package Weight |
4.025 lb
|
| Box Dimensions (LxWxH) |
14.8 x 9.6 x 3.5"
|
