Description
Product Overview
MPCMA36-S-DC24V-A-R is a sealed, NO, quick connect type automotive relay.
- 50A of switching capability, SPST and SPDT contact form
- SPST-NO contact form, Ag alloy contact material
- 50mohm (24VDC/1A) max contact resistance, 100,000 cycles electrical life
- 100Mohm 500VDC min insulation resistance, 1,000,000 cycles (300 cycles/minutes) mechanical life
- 10ms max operate time and 10ms max release time
- 24VDC nominal voltage, 288 ohm ±10% coil resistance
- 16VDC operate voltage, 2.4VDC release voltage, 2.2W coil power
- Operating temperature range from -40°C to +125°C
- Dimension is 26mm × 26mm × 22.7mm
Product details
Other details
| Brand | MULTICOMP PRO |
| Part Number | MPCMA36-S-DC24V-A-R |
| Quantity | Each |
| Technical Data Sheet EN |  |
