Description
Product Overview
JTE06 series is a 6W regulated, DC-DC converter in a DIP24 PCB mount package housed in plastic case. The JTE06 provides 1.5KVDC isolation between input and output. Safety approvals are UL62368-1, CAN/CSA C22.2 No. 62368-1.
- 4:1 input range
- 3 year warranty
- Input voltage is 9-36V
- Output voltage is ±24V
- Output current is ±125mA
- Input current is 308mA full load
- ±47?F maximum capacitive load per maximum capacitive load is per output
- Efficiency is 82%
- Trip and restart (hiccup mode), auto recovery short circuit protection
- Operating temperature is -40°C to +100°C, derate from 100% load at +60°C to no load at +100°C
Product details
Other details
| Brand | XP POWER |
| Part Number | JTE0624D24 |
| Quantity | Each |
| Technical Data Sheet EN |  |
