Description
Product Overview
The THN 30-4822WI is a 2-output 30W board-mount isolated high performance DC/DC Converter with highest power density. It offers 18 to 75VDC input voltage range and ±12VDC output voltage. The device has an ultra wide 4:1 input voltage range and precisely regulated output voltages, even under no load conditions. Highest efficiency across full load range makes this device very reliable and applicable in temperature ranges of up to 85°C. With a low input current at minimal load and remote ON/OFF control this converter is ideal solution for battery-operated systems. This device is suitable for use in many applications where space on the PCB is critical.
- Shielded metal case with isolated base plate
- No minimum load required
- Overtemperature protection
- Output voltage adjustable
- 1500VDC I/O isolation voltage
- 91% Typical efficiency
- 48VDC Nominal input voltage
Applications
Power Management, Industrial, Communications & Networking, Sensing & Instrumentation
Product details
Other details
| Brand | TRACO POWER |
| Part Number | THN 30-4822WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
