Description
The TMR 1-2423 is a 2-output 1W board-mount isolated DC/DC Converter with regulated output, featuring wide 2:1 input voltage ranges. It offers 18 to 36VDC input voltage range and ±15VDC output voltage. An excellent efficiency allows 40 to 85°C operation temperature. Further features include remote ON/OFF control and continuous short-circuit protection. The compact dimensions and optimised design make this converter an ideal solution for many applications.
- Fully regulated outputs
- No minimum load required
- 1500VDC I/O isolation
- 80% Typical efficiency
- 24VDC Nominal input voltage
Power Management, Industrial, Sensing & Instrumentation, Communications & Networking
Other details
| Brand | TRACO POWER |
| Part Number | TMR 1-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| CAD Multiple Formats EN | |
