Description
The TMM 24105C is a fully encapsulated AC/DC Power Supply Module features a reinforced/double I/O isolation system according to latest medical safety standard 60601-3 3rd edition. The high efficiency and the use of highest grade components make the units suitable for an operating temperature range of -40 to +65°C while it goes up to 80°C with 50% load derating.
- Fully encapsulated low profile plastic casing
- Ready to meet ErP directive <0.3W no load power consumption
- Protection against over-temperature, overload and short-circuit
- Safety class II prepared
- 77% Efficiency
- 80µA Typical leakage current
- <0.3W No-load power consumption
- T2A 250VAC (both life and neutral) Internal fuse
- 0.02%/°C Temperature coefficient
Power Management, Medical, Industrial, Commercial
Other details
| Brand | TRACO POWER |
| Part Number | TMM 24105C |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Technical Data Sheet EN | |
| Operating Instructions EN | |
| CAD Multiple Formats EN | |
