Description
Product Overview
The THN 15-2422WI is a 2-output 15W board-mount isolated high performance DC/DC Converter setting new standards concerning power density. It offers 9 to 36VDC input voltage range and ±12VDC output voltage. The device has ultra wide 4:1 input voltage range and precisely regulated output voltages. Advanced circuit design provides high efficiency which allow operating temperature range of -40 to 85°C (with derating). Further features include remote ON/OFF and trimmable output. This converter is suitable for use in many applications where space on PCB is critical.
- Shielded metal case with isolated base plate
- Output voltage trim
- Industry standard pin-out
- 1500VDC I/O isolation voltage
- 87% Typical efficiency
- 24VDC Nominal input voltage
Applications
Power Management, Industrial, Communications & Networking, Sensing & Instrumentation
Product details
Other details
| Brand | TRACO POWER |
| Part Number | THN 15-2422WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5948.65 |
| 3-5 | ₹ 5887.95 |
| 5-10 | ₹ 5766.55 |
| 10+ | ₹ 5645.15 |
Bulk discount will be automatically applied during checkout based on quantity.
