Description
Product Overview
The TEN 20-4813WIN is a high performance 20W DC/DC Converter Module featuring ultra wide 4:1 input voltage ranges 18 to 75VDC and 15VDC output with industry-standard footprint. A very high efficiency allows an operating temperature range of -40 to 85°C. The standard features include 15VDC output voltage, remote ON/OFF, output voltage trimming, over voltage protection and short-circuit protection. The applications for this converter are everywhere where isolated, tightly regulated voltages are required.
- No minimum load required
- Adjustable output voltage
- Shielded metal case with insulated base plate
- 1500VDC I/O isolation
- 87% Typical efficiency
- 48VDC Nominal input voltage
Applications
Communications & Networking, Consumer Electronics
Product details
Other details
| Brand | TRACO POWER |
| Part Number | TEN 20-4813WIN |
| Quantity | Each |
| Technical Data Sheet EN |  |
