Description
The TEL 2-4812 is an isolated 2W DC/DC Converter requires only 3.25cm² of space on the PCB it provides a complete DC/DC converter without need of any external components. Wide input range of 36 to 75VDC and 5VDC output, tightly regulated output voltage qualifies this converter for many applications.
- Regulated output
- Low ripple and noise
- Indefinite short-circuit protection
- Wide 2:1 input range
- 1500V I/O isolation
- 79% Typical efficiency
- 48VDC Nominal input voltage
Industrial, Consumer Electronics
Footnotes NRND - Not Recommended for New DesignsOther details
| Brand | TRACO POWER |
| Part Number | TEL 2-4812 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| CAD Multiple Formats EN | |
| Miscellaneous EN | |
