| ₹ 9341.97 includes GST and import duties. | |
| B2B customers can avail ₹ 1424.65 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
MGFW802412 is a MGFW80 series PCB mount DC-DC converter in an industry standard 1"X2" package. It features include built-in overcurrent protection circuits (recovers automatically), built-in remote ON/OFF and a six-sided shield.
- Input voltage range from 9V to 36V
- Output power of 81.6W
- Output voltage of ±12V, output current of 3.4A/3.4A
- I/O isolation voltage DC1,500V (1 minute)
- High reliability : not built-in aluminium and tantalum electrolytic capacitor
- Operating temperature/humidity of -40 to +85?, 20 to 95%RH (non condensing) (required derating)
- UL62368-11, C-UL, EN62368-1 safety approvals
- 25.4 x 9.9 x 50.8mm (W x H x D) case size
- 10 year warranty
Product details
Other details
| Brand | COSEL |
| Part Number | MGFW802412 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 9155.13 |
| 3-5 | ₹ 9061.71 |
| 5-10 | ₹ 8874.87 |
| 10+ | ₹ 8688.03 |
Bulk discount will be automatically applied during checkout based on quantity.
