| ₹ 14520.03 includes GST and import duties. | |
| B2B customers can avail ₹ 2214.3 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
The MAX77651EVKIT# from Maxim Integrated Products is a MAX77651 evaluation kit. It is a fully assembled and tested printed circuit board (PCB) that demonstrates the MAX77651. The EV kit allows for easy evaluation of the various MAX77651 features, including the SIMO buck-boost regulator, linear regulator, analogue multiplexer, smart battery charger, on/off controller and I2C interface. EV kit is identical aside from the device (U1), silkscreen and two resistive dividers at the SIMO outputs. The MAX77651 device themselves have different output voltage ranges for the SIMO buck-boost regulator. Windows�-based software provides a user-friendly graphical interface as well as a detailed register-based interface to exercise the features of the MAX77651.
- GUI drives I2C interface
- On-board battery ammeter
- On-board thermistor
- RGB LED cluster
- Emulates system loading
- On-board electronic loads
- Electronic loads have steady-state, transient and random modes
- Demonstrates end to end analogue multiplexer implementation
- On-board ADC
- Evaluates both push-button and slider-switch on-key options
Applications
Power Management
Product details
| Kit Application Type | Power Management - Battery |
| Kit Contents | Eval Board MAX77651 |
| Silicon Core Number | MAX77651 |
| Product Range | - |
| Silicon Manufacturer | Maxim Integrated Products |
| Application Sub Type | Li-Ion / Polymer Battery Charger |
Other details
| Brand | MAXIM INTEGRATED PRODUCTS |
| Part Number | MAX77651EVKIT# |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 14229.63 |
| 3-5 | ₹ 14084.43 |
| 5-10 | ₹ 13794.03 |
| 10+ | ₹ 13503.63 |
Bulk discount will be automatically applied during checkout based on quantity.
