Description
BZBGear CSA Overview
- 1Description
- 2Key Features
- 3System Requirements
- 4Applications
Ingest video footage into your computer for editing or streaming from a 3G-SDI source with this 3G-SDI to USB 3.1 Gen 1 1080p Video Capture Device with Audio Embedding from BZB Gear. The capture device lets you import 3G-SDI video with up to 1080p60 resolution from various devices directly into your macOS or Windows computer with a USB port.
There is a 3.5mm stereo audio input that can be used to embed a separate analog audio source such as a microphone or audio player into your video, or you can select embedded 3G-SDI audio to pass through to the output using a switch. The capture device ingests footage using H.264 compression so it can be used for live streaming by connecting cameras and gaming systems, or for post-production purposes for video previews, editing, and storage. The unit is powered using the host USB connection, so there is no need for a separate power cable.
Key Features
System Requirements
Operating System
Processor
Laptop: Intel Core i7-4810MQ + NVIDIA GeForce GTX 870M or higher
RAM
Applications
In the Box
- BZBGear 3G-SDI to USB 3.1 Gen 1 1080p Video Capture Device with Audio Embedding
- USB 3.0 Type-A Cable
- 5 VDC Wall Adapter
- Limited 1-Year Warranty
- Description
- Key Features
- System Requirements
- Applications
BZBGear CSA Specs
| Host Connection | USB Type-A (USB 3.2 Gen 1 / USB 3.1 Gen 1 / USB 3.0) |
| Video Input Connectors | 1 x BNC (3G-SDI) Female |
| Input Video Format | SDI 1080p: 23.98/24/25/29.97/30/50/60 fps 720p: 24/25/30/50/60 fps SXVGA (1280 x 1024): 24/25/30/50/60 fps XGA (1024 x 768): 24/25/30/50/60 fps SVGA (800 x 600): 24/25/30/50/60 fps 480p: 30/60 fps |
| Audio Input Connectors | 1 x 1/8" / 3.5 mm TS Stereo Analog Female |
| Input Audio Format | Analog: 48 kHz / 16-Bit |
| Embedded Audio Input | SDI: 2-Channel (per Input) |
| Output Video Format |
USB Type-A 1080p: 60 fps |
| Output Audio Format | Analog: 48 kHz / 16-Bit |
| Embedded Audio Output | USB Type-A: 2-Channel |
| OS Compatibility | macOS Windows 7 or Later Linux |
| Power Consumption | Device: 4 W |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Humidity | 20 to 90% |
| Certifications | CE, FCC, RoHS, as per Manufacturer |
| Weight | 4.8 oz / 135 g |
| Warranty Length | Limited 2-Year Warranty |
| Package Weight | 0.6 lb |
| Box Dimensions (LxWxH) | 6.5 x 4.9 x 1.8" |
BZBGear CSA Reviews
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 30713.2 |
| 3-5 | ₹ 30399.8 |
| 5-10 | ₹ 29773.0 |
| 10+ | ₹ 29146.2 |
Bulk discount will be automatically applied during checkout based on quantity.
