Description
Product Overview
DIB01CD485A is a 1-phase true RMS AC/DC over or under current monitoring relay. Owing to the built-in latch function, the ON position of the relay output can be maintained. The inhibit function can be used to avoid relay operation when not desired (maintenance, transitions). The LEDs indicate the state of the alarm and the output relay. Through the built-in shunt, it is possible to monitor loads upto 10A AC/DC.
- Current measuring through internal shunt, adjustable current on relative scale
- Adjustable hysteresis on relative scale, adjustable delay function (0.1 to 30s)
- Programmable latching or inhibit at set level, LED indication for relay, alarm and power supply ON
- Galvanically separated power supply, supply voltage is 24 to 48VAC/DC
- Measuring range from 0.1 to 5A AC/DC, SPDT output, DIN-rail mounting
- Dielectric voltage is ? 2kVAC (rms), rated impulse withstand voltage is 4kV (1.2/50µs)
- IP20 degree of protection, EN 60255-6 standard, UL, CSA, CCC (GB/T14048.5) approval
- Dimension is 22.5 x 80 x 99.5mm, repeatability is ±0.5% on full-scale
- Temperature drift is ±1000ppm/°C, operating temperature range from -20°C to 60°C
Product details
Other details
| Brand | CARLO GAVAZZI |
| Part Number | DIB01CD485A |
| Quantity | Each |
| Technical Data Sheet EN |  |
