ZEISS Terra ED 10x25 Overview
-
1Description
-
2Optical Performance
-
3Use and Handling
-
4Construction Details
Sleek and stylish with black body and blue accents, ZEISS's 10x25 Terra TL Compact Binoculars give you a competent and compact optic that fits easily in the palm of your hand and looks good while they are there. A combination of technologies works together to produce bright and clear images with increased contrast and true color rendition. They include Schmidt-Pechan roof prisms, SCHOTT extra-low dispersion (ED) glass, and anti-reflection fully multicoated optics. The Terra ED is offered here in a 10x power, which walks the delicate line between an increased viewing distance over lower magnification optics while maintaining a useful field of view.
Optimized for travel, the Terra TL comes with a drawstring case for easy packability and a slim neck strap. The lightweight housing is nitrogen filled and O-ring sealed, enabling them to withstand use in wet and snowy weather, and the rubberized armor offers protection from impacts while providing a slip-resistant grip. The Terra's double-hinge closed-bridge design allows them to fold compactly for an easy fit in most pockets or packs, while the knurled center focus wheel enables fast focusing. Twist-up eyecups make them comfortable to use with or without eyewear.
This open-box item comes with the manufacturer's limited lifetime warranty.
- 10x magnification
- 25mm objective lenses
- Schmidt-Pechan roof prisms
- Extra-low dispersion (ED) glass: Corrects chromatic aberration for true color rendition and improved contrast
- Proprietary ZEISS hydrophobic and anti-reflection fully multicoated optics
- Apparent angle of view: 54°
- 291' field of view at 1000 yd
- Closed-bridge configuration
- Knurled center focus wheel
- Twist-up rubber eyecups
- +3/-3 right eye dioptric correction, center adjustment wheel
- Interpupillary adjustment range: 35-72mm
- 16mm long eye relief
- 2.5mm exit pupil
- Sleek & stylish with a black body and blue accents
- Protective rubber-armored grips
- Nitrogen filled for water and fogproof performance
- Test to 100mbar of pressure against ingress of water
- Functional temperature range: 4 to 145°F (-15 to 62°C)
- Weight: 10.9 oz
In the Box
- ZEISS 10x25 Terra TL Compact Binoculars (Night Blue/Black, Open Box)
- Case
- Neck Strap
- Cleaning Cloth
Table of Contents
- Description
- Optical Performance
- Use and Handling
- Construction Details
ZEISS Terra ED 10x25 Specs
Prism Type |
Schmidt-Pechan |
Performance
Magnification |
10x |
Objective Lens Diameter |
25 mm |
Angle of View |
54° (Apparent) |
Field of View |
291' @ 1000 yd / 96.6 m @ 1000 m |
Minimum Focus Distance |
5.7' / 1.74 m |
Exit Pupil Diameter |
2.5 mm |
Eye Relief |
16 mm |
Interpupillary Adjustment |
35 to 72 mm / 1.4 to 2.8" |
Diopter Adjustment |
-3 to +3 |
Focus Type |
Center |
Features
Fogproof |
Yes, Nitrogen Filled |
Water Resistance |
Waterproof |
General
Dimensions |
4.5 x 4.4" / 11.4 x 11.2 cm |
Weight |
10.9 oz / 309 g |
Packaging Info
Package Weight |
1.075 lb |
Box Dimensions (LxWxH) |
5.7 x 5.3 x 2.6" |
