| ₹ 13500.8 includes GST and import duties. | |
| B2B customers can avail ₹ 2058.87 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
The Q Series is a broad line of ultra-miniature, high reliability DC to HV DC converters supplying up to 5,000 volts in only 0.125 cubic inches and up to 10,000 volts in only 0.614 cubic inches. Input voltage can be 5V, 12V, 15V, or 24V. The output is directly proportional to the input voltage and is linear from
- Output voltages from 100VDC to 10,000VDC
- Output Proportional to Input
- 0.7VDC Turn-on Voltage
- Wide Operating Temperature Range
- Short Circuit Protection
- Low Ripple <1%
- 500VDC Input to Output Isolation
- No minimum load
- See Technical Note for information about XP Power's plans for the UKCA Marking
Power Management
Other details
| Brand | XP POWER |
| Part Number | Q03-12 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Technical Notes & Articles EN | |
| CAD Multiple Formats EN | |
| Certificate of Conformity EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 13230.78 |
| 3-5 | ₹ 13095.78 |
| 5-10 | ₹ 12825.76 |
| 10+ | ₹ 12555.74 |
Bulk discount will be automatically applied during checkout based on quantity.
