Description
Product Overview
ECS65 series is an AC-DC power supply. With high efficiency, high power density, low leakage currents and medical 2 X MOPP rating, the ECS65 is ideal for medical, industrial electronics and ITE applications requiring a compact, high power density chassis mount power supply. Safety approvals are IEC60950-1:2005 Ed 2 / IEC62368-1:2014, UL 62368-1 and CAN/CSA C22.2 No. 62368-1-14, EN62368-1:2014/A11:2017, IEC60601-1 CB report, CSA 22.2 No. 60601-1, ANSI/AMMI ES60601-1, TUV 60601-1.
- IT and medical safety approvals
- Class I and class II construction
- Industry standard 50.8mm x 101.6mm package
- <lt/>0.5W no load input power
- Low leakage current
- 3 year warranty, internal T3.15A/250V fuse in line and neutral input protection
- Output power is 65W, input frequency is 47-63Hz
- Output voltage is 24V, output current is 2.7A, efficiency is up to 90%
- Input voltage is 80-264VAC derate output power <lt/>90VAC
- Operating temperature is -20?C to 70?C, derate linearly from 50?C at 2.5%/?C to 50% load at 70?C
Product details
Other details
| Brand | XP POWER |
| Part Number | ECS65US24 |
| Quantity | Each |
| Technical Data Sheet EN |  |
