- Compact Size
- IT & Medical Approvals
- Convection Cooled
- Class I and II Construction
- Level B Conducted Emissions
- See Technical Note for information about XP Power's plans for the UKCA Marking
Product details
| Power Supply Applications:
ITE & Medical
|
| Power Rating (Forced Cooling):
-
|
| Power Rating (Convection Cooling):
40W
|
| Input Voltage VAC:
90V AC to 264V AC
|
| Power Supply Output Type:
Adjustable, Fixed
|
| Output Voltage - Output 1:
5VDC
|
| Output Current - Output 1:
6A
|
| Output Voltage - Output 2:
12VDC
|
| Output Current - Output 2:
2A
|
| Output Voltage - Output 3:
-12VDC
|
| Output Current - Output 3:
500mA
|
| Output Voltage - Output 4:
-
|
| Output Current - Output 4:
-
|
| Product Range:
ECM40 Series
|
Other details
| Brand |
XP POWER |
| Part Number |
ECM40UT31 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
