Description
X-keys XK-1332-UUHS14-R Overview
The USB 14-Input HD15/3.5mm Wire Interface from X-keys allows you to create custom control panels and hidden inputs for various interfaces, while emulating HID keyboard, mouse and joystick hardware. The wire interface features ten HD15 input connectors and four inputs via two 3.5mm stereo ports. In addition, it features two digital HD15 outputs, and an internal memory for hardware. The unit is compatible with the X-keys 4, 6 and 8 button pendants and foot switches, and operates with MacroWorks 3.1 for Windows XP through 10.
Create custom control panels
Ten HD15 input ports
Four 3.5mm audio ports
Two digital HD15 outputs
HID keyboard, HID mouse, HID game controller, and HID multimedia support
Up to 1000' wiring distance from switch to port
Two 0.19" DIA mounting holes, 3" O.C.
Approximately 1000 keystrokes or commands in onboard memory
EEPROM, non-volatile memory
IP40 rated for indoor office environment
MacroWords 3.1 software for Windows, ControllerMate for X-keys and X-keys Android (free download)
In the Box
- X-keys USB 14-Input HD15/3.5mm Wire Interface
- Limited 1-Year Manufacturer Warranty
X-keys XK-1332-UUHS14-R Specs
| Operating System |
Programming: Windows XP to 10
Mac OS X 10.4 to 10.1 |
| Programming Software |
Windows: MacroWorks 3.1
Mac: ControllerMate for X-keys |
| Installation |
HID Keyboard
HID Mouse HIDE Game Controller HID Multimedia |
| Input Connectors |
10 x 15-Pin Sub-D, Video Input
2 x 3.5 mm TRS Jack, Stereo Input |
| Output |
2 x Digital Output, Controllable, 10 mA @ 5 VDC
|
| USB |
1 x USB 1.1, Type A
|
| Cable Length |
5.9' / 3 m
|
| Wiring Distance |
Up to 1000' / 300 m, Switch to Port
|
| Memory Type |
EEPROM, Non-Volatile Memory
|
| Memory Capacity |
Up to 1200 Keystrokes or Commands
|
| Mounting |
2 x 0.19" Mounting Holes, 3" O.C.
|
| Certifications |
FCC Class B, CE, RoHS, WEEE Compliant
|
| Temperature Range |
-4 to 140°F / -20 to 60°C
|
| Power Input |
USB, 5 VDC
|
| Power Consumption |
21 mA, 5 VDC
|
| Dimensions |
2.55 x 2.55 x 1.01" / 6.5 x 6.5 x 2.6 cm
|
| Weight |
6 oz / 160 g
|
Packaging Info
| Package Weight |
0.545 lb
|
| Box Dimensions (LxWxH) |
7.3 x 5.4 x 1.8"
|
