Description
WyreStorm MX-0808-H2A Overview
- 1Description
- 2
- 3Video Scalers
- 4Up to DCI 4K60 4:4:4
- 5ARC Support
- 6Audio De-Embedding
The
MX-0808-H2A-MK2 4K60 HDR 8x8 HDMI Matrix with Downscaling & ARC from
WyreStorm is an updated 18 Gb/s matrix switcher that can independently route eight 4K video sources to eight displays. Individual scalers provide downscaling of 4K to connected 1080p displays without affecting the UHD 4K sources. ARC (Audio Return Channel) from smart TVs enables audio to be brought from apps like Netflix or Prime Video to an external audio system. The analog audio outputs have been updated to balanced connections to eliminate loss in fidelity.
Video Scalers
- Each of the eight HDMI 2.0 outputs incorporates a 4K to 1080p downscaler.
- This enables you to use a mix of 4K and 1080p screens at their highest potential without affecting 4K sources.
Up to DCI 4K60 4:4:4
- This matrix supports the latest video formats up to DCI 4K60 4:4:4 video at rates up to 18 Gb/s.
- It also supports high frame rate HDR 12-bit 4:2:2 up to UHD 4K60, all in uncompressed HDMI.
ARC Support
- All eight HDMI outputs support ARC (Audio Return Channel) from smart TVs apps like Netflix, Prime Video, Hulu, etc.
- The ARC audio can then be sent through either the digital S/PDIF or balanced analog outputs to an A/V receiver or stereo amplifier.
Audio De-Embedding
- The matrix features both balanced analog and digital S/PDIF.
- This enables you to easily de-embed audio from either the HDMI inputs or ARC to a secondary audio distribution system without the need for external adapters or converters.
In the Box
- WyreStorm MX-0808-H2A-MK2 4K60 8x8 HDMI Matrix with Downscaling & ARC
- AC Power Cord (US/UK/EU/AU)
- 8 x 3.5mm 5-Pin Terminal Block
- 3.5mm 3-Pin Terminal Block
- IR Remote (CR2025 Battery Not Included)
- 2 x Rack Mounting Bracket with Screws
- Limited 5-Year Manufacturer Warranty
Table of Contents
- Description
- Video Scalers
- Up to DCI 4K60 4:4:4
- ARC Support
- Audio De-Embedding
WyreStorm MX-0808-H2A Specs
Processing
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
DCI 4K at 60
|
| Color Processing |
16-Bit
12-Bit 4:2:0 10-Bit 4:2:2 8-Bit 4:4:4 |
Input
| Video Inputs |
8x HDMI (2.0) Female
|
| Input Video Format |
HDMI (8-Bit 4:4:4)
DCI 4K up to 60 fps HDMI (10-Bit 4:2:2) UHD 4K up to 60 fps HDMI (12-Bit 4:2:0) UHD 4K |
| Embedded Audio Input |
HDMI
|
Output
| Video Outputs |
8x HDMI (2.0) Female
|
| Output Video Format |
HDMI (8-Bit 4:4:4)
DCI 4K at 60 fps HDMI (10-Bit 4:2:0) UHD 4K at 60 fps HDMI (16-Bit) 1080p at 60 fps |
| Audio Outputs |
8x Block 5-Pin Analog Female
8x TOSLINK Female |
| Embedded Audio Output |
HDMI
|
Connectivity
| Other I/O |
1x Block 3-Pin RS-232 Input/Output
1x RJ45 Control, LAN Input/Output |
| HDCP Support |
Yes, Version 2.2
|
| HDR Compatibility |
HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
|
| DTS Compatibility |
DTS:X
|
| Dolby Compatibility |
Dolby Atmos
|
Hardware
| Wi-Fi |
No
|
| Bluetooth |
No
|
Power
| Power I/O |
1x IEC C14 Input
|
| Power Consumption |
Power Supply: 100 to 240 VAC (60 W)
|
Environmental
| Operating Temperature |
32 to 113°F / 0 to 45°C
|
| Storage Temperature |
-4 to 158°F / -20 to 70°C
|
| Operating Humidity |
10 to 90%
|
| Storage Humidity |
10 to 90% (Non-Condensing)
|
General
| Certifications |
CE, EAC, FCC, RCM, RoHS
|
| Rack Form Factor |
1 RU
|
| Dimensions |
17.3 x 11.8 x 1.7" / 440 x 300 x 43.5 mm
|
| Weight |
7.89 lb / 3.58 kg
|
