Description
The 690157001272 is a 12-position 2-row male IDC Connector with stamped matt tin over nickel-plated phosphor bronze contacts and red glass-filled polyester housing. It mates with female SMT connector with latch and polarization WR-MM, female SMT connector with polarization WR-MM, female connector with latch and without polarization WR-MM, female connector without latch and polarization WR-MM, female angled connector with latch and polarization WR-MM, female angled connector with polarization and w/o latch WR-MM and female angled connector without latch and polarization WR-MM.
- UL94V-0 Housing Flammability
- 10mR Maximum contact resistance
- 1000MR Insulation resistance
Applications
Industrial
Product details
| IDC Connector Type: IDC Plug |
| Contact Gender: Male |
| Pitch Spacing: 2.54mm |
| No. of Rows: 2 Row |
| No. of Contacts: 12Contacts |
| Connector Mounting: Cable Mount |
| Contact Material: Phosphor Bronze |
| Contact Plating: Tin Plated Contacts |
| Product Range: WR-MM Series |
Other details
| Brand | WURTH ELEKTRONIK |
| Part Number | 6.90157E+11 |
| Quantity | Each |
| Technical Data Sheet EN |  |
