Description
Wisycom BFA-B-F2 Overview
The Wisycom BFA-F2 Wideband Antenna Amplifier features an advanced bank of filters combined with a low-noise amplifier. Filters and gain can be easily configured either locally via a TFT display and a four-button navigation system or remotely through an RF coaxial cable data connection. Leveraging Wisycom�s latest filter technology, the BFA-F2 provides full control over RF zones, enabling the creation of flexible and remotely controllable antenna systems.
F2 Filter Option
- Tunable filter for interference control: 430 to 730 MHz (40 MHz-wide)
- Fixed-band saw filter: 940 to 960 MHz (USA)
- 3 high-pass filters (410/520/550 MHz) and 3 low-pass filters (617/663/698 MHz) CASCADE-9 bandpass combinations (USA/EU)
At a Glance
- BNC connectors
- Wide reception band: 430 to 960 MHz
- RF gain from -12 to +27 dBu (1-dB step)
- Can be entirely controlled and monitored remotely by Wisycom Manager software and Wisycom MAT288/244 and SPL2216/2208 devices or Sound Devices SL2 multislot unit.
- Local configuration through TFT display and four key navigation buttons
- Antenna off for RF zone disabling
- Pass-through DC selectable for device cascading
- Requires +12 VDC / 100mA for full operation
- Waterproof with gasket sealing
Items Included
- Wisycom BFA-F2 Wideband Antenna Amplifier with Remoted-Controlled Filters and BNC Connectors (430 to 960 MHz)
- Limited 1-Year Manufacturer Warranty
Additional Resources
Wisycom BFA-B-F2 Specs
General
| Compatibility |
Wisycom MAT288/244 / SPL2216/2208
Sound Devices SL2 Multislot Unit |
| Operating Frequency |
F2: 430 to 960 MHz
|
| Gain |
-12 to +27 dBu
|
Display
| Panel Type |
TFT LCD
|
| Display Size |
Not Specified by Manufacturer
|
| Touchscreen |
No
|
Inputs/Outputs
| Input and Output Connectors |
Input: 1 x Coaxial BNC
Output: 1 x Coaxial BNC |
Power
| Power Source |
DC Input (Included)
|
| DC Input Power |
9.5 to 16 VDC
|
Physical
| Mounting |
1x Holes
|
| Dimensions |
4.7 x 1.9 x 1.2" / 120 x 48 x 30 mm
|
| Weight |
0.6 lb / 250 g
|
Packaging Info
| Package Weight |
0.58 lb
|
| Box Dimensions (LxWxH) |
6.35 x 4.35 x 2.65"
|
