Description
The 1690190000 is a 2-pole orange female PCB Plug-in Connector with clamping yoke connection. The BL 3.50/02/180 SN OR BX connector has tinned Cu-leg contact with 4 to 8µm Sn hot-dip tinned layer structure of plug contact and a PBT insulator. The female plug is suitable for wire connecting conductors 3.5mm pitch. The female plug provides space for labelling and can be coded.
- Safe from finger touch
- >=10�R Insulation resistance
- 5mR Volume resistance
- DIN 5264-A Screwdriver blade standard
- IP20 Protection
- UL94V-0 Flammability
- -50 to 100°C Operating temperature range
Applications
Industrial
Product details
| Pitch Spacing: 3.5mm |
| No. of Positions: 2Ways |
| Wire Size (AWG): 26AWG to 14AWG |
| Conductor Area CSA: 1.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 10A |
| Rated Voltage: 300V |
| Product Range: - |
Other details
| Brand | WEIDMULLER |
| Part Number | 1690190000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
