| ₹ 2317.23 includes GST and import duties. | |
| B2B customers can avail ₹ 353.38 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 1650780000 is a 16-position heavy-duty Female Insert with screw connection. The HDC series insert made of PC glass-fiber reinforced (UL-listed and railway-certified). It is suitable for use with HA series rectangular power connectors.
- 2.5mm² Conductor cross-section
- <=2mR Volume resistance
- 10¹�R Insulation resistance
- >=500 Plugging cycles (silver)
- 16A Rated current (DIN EN 61984)
- 4kV Rated impulse voltage (DIN EN 61984)
- 250V Rated voltage (DIN EN 61984)
- UL94V-0 Flammability rating
- -40 to 125°C Limit temperature range
Power Management
Other details
| Brand | WEIDMULLER |
| Part Number | 1650780000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 2270.89 |
| 3-5 | ₹ 2247.71 |
| 5-10 | ₹ 2201.37 |
| 10+ | ₹ 2155.02 |
Bulk discount will be automatically applied during checkout based on quantity.
