Description
The 1615680000 is a 3-pole black female PCB Plug-in Connector with clamping yoke connection. The BL 3.50/03/180 SN BK BX connector has tinned Cu-leg contact with 4 to 8µm Sn hot-dip tinned layer structure of plug contact and a PBT insulator. The female plug is suitable for wire connecting conductors 3.5mm pitch. The female plug provides space for labelling and can be coded.
- Safe from finger touch
- >=10�R Insulation resistance
- 0.2 to 0.25Nm Tightening torque
- DIN 5264 Screwdriver blade standard
- IP20 Protection
- UL94V-0 Flammability
- -50 to 100°C Operating temperature range
Industrial
Other details
| Brand | WEIDMULLER |
| Part Number | 1615680000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
