Description
The 1478130000 from Weidmuller is a 240W, 24V & 10A switch mode power supply unit. It features horizontal on TS35 mounting rail, 50mm of clearance at top & bottom for air circulation, can mount side by side with no space in between and LED red/green and relay (>=21.6 V DC LED green, relay on/ <= 20.6 LED red, relay off) status indication.
- Dimension is 60mm x 130mm x 125mm ( W x H x D)
- Operating temperature range from -25°C to 70°C
- Screw connection, III surge voltage category
- Current limiting is greater than 120% IN
- Degree of efficiency is 91.5%
- Metal, corrosion resistant housing version, MTBF >500.000h (25°C, IEC 61709)
- IP20 protection degree
- Conductor cross section range from 26AWG to 10AWG (input) and 26AWG to 10AWG (output)
- GERMLLOYD 14076-15, cULus E258476, cULusEX E470829VOL1SEC2, cURus E255651 approved
- Series switching capability and short circuit protection
System Monitoring
Other details
| Brand | WEIDMULLER |
| Part Number | 1478130000 |
| Quantity | Each |
| Technical Data Sheet EN |  |
