Description
The WF08W series resistors from Walsin are high precision thin film chip resistors. These resistors are constructed in a high grade ceramic body (aluminium oxide).
- Resistance range includes E24 & E192 decade values from 25ohm to 200Kohm
- EIA 0805 case size
- TCR of ?10ppm/°C
- Available in ±0.05%, ±0.1%, ±0.25%, ±0.5% tolerance
- Operating temperature range of -55°C to 155°C
- High reliability and stability of 0.25%
- Low current noise
- Continuous working voltage is 100V and rated power is 125mW
Applications
Industrial, Power Management, Consumer Electronics, Portable Devices
Product details
| Resistance | 10.2kohm |
| Resistor Case Style | 0805 [2012 Metric] |
| Voltage Rating | 100V |
| Resistor Element Material | Thin Film |
| Resistance Tolerance | ± 0.1% |
| Product Range | WF08W Series |
| Automotive Qualification Standard | - |
| Temperature Coefficient | ± 10ppm/°C |
| Power Rating | 125mW |
| Packaging | Cut Tape |
Other details
| Brand | WALSIN |
| Part Number | WF08W1022BTL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
