![WALSIN WF06U2491BTL SMD Chip Resistor, 2.49 kohm, 50 V, 0603 [1608 Metric], 62.5 mW, � 0.1%, WF06U Series](http://www.tanotis.com/cdn/shop/products/2447094-40_1bdfef3f-77bb-4316-8f7a-6fc19e341ecd_{width}x.jpg?v=1575993631)
![WALSIN WF06U2491BTL SMD Chip Resistor, 2.49 kohm, 50 V, 0603 [1608 Metric], 62.5 mW, � 0.1%, WF06U Series](http://www.tanotis.com/cdn/shop/products/2447094-40_1bdfef3f-77bb-4316-8f7a-6fc19e341ecd_1024x.jpg?v=1575993631)
| ₹ 40.28 includes GST and import duties. | |
| B2B customers can avail ₹ 6.14 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The WF06U series resistors from Walsin are high precision thin metal film chip resistors. These resistors are constructed in a high grade ceramic body (aluminium oxide).
- Resistance range includes E24 & E192 decade values from 4.7ohm to 680Kohm
- EIA 0603 case size
- TCR of <=25ppm/�C
- Available in �0.05%, �0.1%, �0.25%, �0.5%, �1% tolerance
- Operating temperature range of -55�C to 155�C
- High reliability and stability of 0.1%
- Low current noise
- JIS C5201-1 / IEC 60115-1 basic specification
- Continuous working voltage is 50V and rated power is 62.5mW
Applications
Industrial, Power Management, Consumer Electronics, Portable Devices
Product details
| Resistance | 2.49kohm |
| Resistor Case Style | 0603 [1608 Metric] |
| Voltage Rating | 50V |
| Resistor Element Material | Thin Film |
| Resistance Tolerance | � 0.1% |
| Product Range | WF06U Series |
| Automotive Qualification Standard | - |
| Temperature Coefficient | � 25ppm/�C |
| Power Rating | 62.5mW |
| Packaging | Cut Tape |
Other details
| Brand | WALSIN |
| Part Number | WF06U2491BTL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
