Description
The 2004-1307 from Wago is 3 conductor ground terminal block. The housing material is polyamide (PA 6.6). It has 3 connection points and 1 potential point and it is suitable for Ex e II applications.
- Push-in CAGE CLAMP connection technology
- Dimension is 6.2mm x 65.5mm x 32.9mm (W x L x H)
- Wire size range from 20AWG to 10AWG
- Nominal cross section of 4mm�
- Green-yellow colour terminal block
- Rated voltage of 800V and nominal current of 32A with front entry wiring
- Weight is 14.58g
- DIN 35 rail mounting
- Horizontal design
Applications
Industrial
Product details
| Wire Size AWG Max | 10AWG |
| Wire Connection Method | Clamp |
| Rated Current | 32A |
| No. of Positions | 3Ways |
| Conductor Area CSA | 6mm� |
| Product Range | 2004 Series |
| No. of Levels | 2 |
| Wire Size AWG Min | 20AWG |
| Rated Voltage | 800V |
Other details
| Brand | WAGO |
| Part Number | 2004-1307 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1738.7 |
| 3-5 | ₹ 1720.95 |
| 5-10 | ₹ 1685.47 |
| 10+ | ₹ 1649.99 |
Bulk discount will be automatically applied during checkout based on quantity.
