Description
Vizrt TriCaster Mini X HDMI Bundle Overview
Outfitted with everything you need to take your production on the go, the NewTek TriCaster Mini X HDMI Bundle includes one TriCaster Mini X HDMI/NDI hybrid input switcher, a control surface to control it with, and a custom hard case to store it all. Simultaneously broadcast, stream, and record with the Mini X's integrated software with its four HDMI and eight NDI inputs. Other expansive connections ensures seamless integration with your live event production.
The NewTek TriCaster Mini X HDMI is the ultimate live-production tool with multiple HDMI, NDI, mini DisplayPort, and USB connections that support up to 4K video for switching and media playback. The Mini X can add graphics, record, livestream, and perform other network-driven functions simultaneously, along with four HDMI inputs that accept various AV equipment. The Mini X offers four mini DisplayPort outputs, which come with four HDMI adapters for expanded compatibility. Various internal software controls allow for chromakeying, switching, streaming, and more advanced audio and video control, depending on what suits your production.
HDMI devices connect directly into the Mini X without requiring configuration for seamless integration into your preexisting production layout. Multiple audio ports support both line and microphone inputs as well as line and headphone outputs for improved sound quality and monitoring. Five USB 3.2 Type-A ports can connect the included keyboard and mouse to the system among other USB-friendly devices. A processing latency of just 1.5 frames ensures all of your equipment communicates efficiently.
- HD switching, streaming, and recording up to 4K30 video
- Real-time social media publishing
- 4 x HDMI video connections, eight IP video inputs via NDI
- IP video output via NDI and four mix outputs
- Multi-channel recording, audio mixing, and internal storage
- Compatible with major streaming platforms
- Video playback without additional hardware
- Built-in live titling and motion graphics
- Two simultaneous Skype video call inputs via software integration
- Up to eight simultaneous PTZ cameras via serial and network protocols with integrated controls and preset system
- Four Mix/effect buses supporting video re-entry
- Five media players and 15 media buffers
- Integrated LiveMatte chroma and luma keying technology on all source channels and mix/effect buses
- LiveSet technology with 30+ virtual sets and box effects
- DataLink for real-time automated data input
- Embedded digital audio outputs and inputs through HDMI conversion
The Control Surface from Newtek brings manual tactile controls to your live production switching with the TriCaster Mini with UHD 4K support while maintaining a small, portable footprint. It is compatible with TriCaster Mini UHD 4K switchers, as well as professional-line TriCaster 8000, 860, 460, and 410 systems.
With an intuitive layout, 14 backlit buttons, a T-bar, familiar live production controls, and a compact frame, the Control Surface is suitable for mobile production even in tight spaces.
- Professional, studio-style workflow for live video productions of any size
- Intuitive layout mapped to the TriCaster Mini live desktop
- 14 large backlit cross-point buttons for Program and Preview rows, as well as Take and Auto transition
- T-Bar for comfortable performance
- Connects to TriCaster via USB
- Combination concentric and pushbutton controls for transition selection, rate, preset speed, and forward/reverse
- Individual control of Main output row or four Mix/Effects rows with control of key channel selection and secondary media player transport control
- Transition delegation of Background, DSK 1, DSK 2, or Fade to Black
- Shift and Alt keys provide additional functionality
- Simple plug-and-play setup
- Compatible with the TriCaster Mini, TriCaster 8000, TriCaster 860, TriCaster 460, and TriCaster 410
In the Box
- Vizrt TriCaster Mini X HDMI
- Keyboard
- Mouse
- 4 x Mini DisplayPort to HDMI Adapter
- Power Cable
- Limited 1-Year Manufacturer Warranty
- Vizrt Control Surface for TriCaster Mini with UHD 4K Support
- Limited 1-Year Manufacturer Warranty
- Custom Travel Case
Additional Resources
No additional resources available
Vizrt TriCaster Mini X HDMI BundleSpecs
| Switching Type |
Software
|
| Latency |
1 to 1.5 Frames
|
| Color Processing |
4:4:4YCbCr
|
| Audio Processing |
96 kHz
|
| Video Inputs |
4x HDMI
2x RJ45 |
| Input Video Format |
HDMI
DCI 4K 25/29.97 fps 1080p 25/29.97/50/59.94 fps 1080i 50/59.94 fps 720p 25/29.97/50/59.94 fps 480p 25/50/59.94 fps |
| Audio Inputs |
1x 1/4" TRS Analog Female
2x 1/4" TRS Analog Female |
| Embedded Audio Input |
HDMI: 2-Channel
|
| Video Outputs |
4x DisplayPort Female
|
| Audio Outputs |
1x 1/4" Balanced TS Female
1x 1/4" TRS Stereo Female |
| Embedded Audio Output |
HDMI
|
| Multiview Output |
3-Way Multiview
|
| Other I/O |
5x USB-A 3.1/3.2 Gen 2 Input
1x USB-C 3.1/3.2 Gen 2 Input |
| Wi-Fi |
Yes
|
| Bluetooth |
No
|
| Power I/O |
1x Barrel Input
|
| Dimensions |
9.08 x 7.89 x 4.23" / 23.06 x 20.04 x 10.74 cm
|
| Weight |
8.4 lb / 3.8 kg
|
| Package Weight |
19.55 lb
|
| Box Dimensions (LxWxH) |
21.8 x 16.6 x 13.3"
|
Vizrt TriCaster Mini X HDMI BundleSpecs
| Controls |
14 x Backlit Buttons
1 x Multimode T-Bar |
| Connectors |
1 x USB
|
| Dimensions |
16.6 x 8 x 2.3" / 42.1 x 20.3 x 5.7 cm
|
| Weight |
4.6 lb / 2.1 kg
|
| Package Weight |
8.54 lb
|
| Box Dimensions (LxWxH) |
20.6 x 13.5 x 8.1"
|
