Vishay WSL1206R0100FEA SMD Current Sense Resistor 0.01 ohm 1206 [3216 Metric] 250 mW ± 1% Metal Strip

The WSL1206R0100FEA is a surface-mount Current Sense Resistor with all welded construction. The Power Metal Strip® resistor is ideal for all types of current sensing, voltage division and pulse applications. The construction is impervious against high sulfur environments and the proprietary processing technique produces extremely low resistance values.

• 0.5 to 5nH Very low inductance
• <3µV/°C Low thermal EMF

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Product details

Resistance	0.01ohm
Product Range	-
Resistor Case Style	1206 [3216 Metric]
Power Rating	250mW
Resistance Tolerance	± 1%
Resistor Element Material	Metal Strip
Temperature Coefficient	± 75ppm/°C
Automotive Qualification Standard	AEC-Q200

Other details

Brand	VISHAY
Part Number	WSL1206R0100FEA
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
Product Change Notice EN
CAD CadSoft_EAGLE EN
Packaging / Drawing / Footprint EN
