Product details
| Channel Type:
P Channel
|
| Drain Source Voltage Vds:
20V
|
| Continuous Drain Current Id:
9.3A
|
| Drain Source On State Resistance:
0.018ohm
|
| Transistor Case Style:
MICRO FOOT
|
| Transistor Mounting:
Surface Mount
|
| Rds(on) Test Voltage:
4.5V
|
| Gate Source Threshold Voltage Max:
900mV
|
| Power Dissipation:
2.7W
|
| No. of Pins:
4Pins
|
| Operating Temperature Max:
150°C
|
| Product Range:
TrenchFET
|
| Qualification:
-
|
Other details
| Brand |
VISHAY |
| Part Number |
SI8425DB-T1-E1 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
