Description
Vanco Evolution HDMI EDID Overview
The Evolution HDMI EDID Sync Recorder from Vanco is an EDID reader/writer/re-timer able to emulate EDID (Extended Display Identification Data) information. For use in applications where EDID issues are occurring, it features the ability to set EDID from the main unit or a connected computer using the included software. Controllable via USB, the unit stores and recalls EDID information from either source or display and supports HDCP. It saves time from troubleshooting and replacing equipment. This EDID management allows and encourages source and display "handshake", a perfect solution for compatibility issues.
Extended Display Identification Data (EDID) is a standard data format that contains basic information about the display and its capabilities, including vendor information, maximum image size, color characteristics, factory pre-set timings, frequency range limits, and character strings for the monitor name and serial number. The information is stored in the display and used to communicate with the system through a Display Data Channel (DDC). The system uses this information for configuration purposes, so the monitor and the system can work together.
- For use in applications where EDID issues are occurring
- Able to read, copy, emulate, and pre-set EDID information to encourage the �handshake� between a source and display
- Features the ability to set EDID from the main unit or a connected computer using the included software
- Saves time from troubleshooting and having to replace equipment
- HDCP 1.1 compliant
- Supports HDMI Deep Color and 3D/DVI 1.1 compliant
- Able to read and store the EDID of displays (monitors or projectors)
- Able to overwrite set EDID into the EDID reader/writer/re-timer or to HDMI displays
- Built-in default EDID
- Maintains HDMI/DVI video resolution
- Prevents PC from deactivating inactive HDMI/DVI ports
- Regenerates EDID content
- Re-synthesizes input HDMI stream and maintains or improves signal integrity
- Controllable by PC/laptop via USB with the included software
In the Box
- Vanco Evolution HDMI EDID Sync Recorder
- 5 VDC Power Supply
- Rack-Mounting Ear Set
Vanco Evolution HDMI EDID Specs
| I/O | Input: 1 x HDMI Type-A Output: 1 x HDMI Type-A |
| HDCP Compatible | Yes |
| Resolution | 1920 x 1200 1600 x 1200 |
| Power Supply | 5 VDC, 2 A |
| Dimensions | 3.58 x 3.14 x 1.1" / 91 x 80 x 28 mm |
