Description
Ubiquiti Networks Door Hub Mini Overview
Designed for indoor use, the UniFi Access Door Hub Mini from Ubiquiti Networks is a single-door mechanism that provides complete entry and exit control via connected Access Readers. It features one GbE/PoE++ RJ45 input and two GbE/PoE RJ45 outputs for providing network connectivity and power to not only the hub, but any readers and cameras. Mounting hardware is included for a seamless installation.
Build Features
2 x 1GbE/PoE RJ45 output ports
1 x GbE/PoE++ RJ45 input
DIN rail mount
Factory reset and dry/wet switch buttons
LED indicators for status
UPC: 810084698839
Items Included
- Ubiquiti Networks UniFi Access Door Hub Mini
- DIN Rail
- Screws & Anchors
- Limited 1-Year Manufacturer Warranty
Additional Resources
No additional resources available
Ubiquiti Networks Door Hub Mini Specs
General
| Compatibility |
Not Specified by Manufacturer
|
| LED Indicators |
Yes
|
| Buttons |
1 x Factory Reset
1 x Dry/Wet Switch |
Inputs/Outputs
| Input Terminals |
1 x Door Exit Request
1 x Door Position |
| Network Interface |
3 x GbE RJ45 Ports
|
| PoE Support |
1 x PoE++ Input (50 VDC, 1 A)
2 x PoE Outputs (Total 31 W) |
Power
| Power Source |
PoE
|
| Power Consumption |
19 W (Typical)
50 W (Maximum) |
Physical
| Mounting |
Back: 1x DIN Rail
|
| Color |
Gray / White
|
| Material of Construction |
Polycarbonate, Metal
|
| Certifications |
CAN, CE, FCC, IC, NDAA, UL
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 5 to 90% Humidity
|
| Dimensions |
4.4 x 2.6 x 1.1" / 113 x 66 x 27.6 mm
|
| Weight |
6.7 oz / 190 g
|
Packaging Info
| Package Weight |
0.695 lb
|
| Box Dimensions (LxWxH) |
6.3 x 3.6 x 2.2"
|
