Description
TRENDnet TI-M6024 Overview
Providing up to 60 watts of power, the TI-M6024 60W Single Output Industrial DIN-Rail Power Supply from TRENDnet is designed to power a variety of devices including switches, network cameras, and Wi-Fi access points. In addition to providing power, this power supply features passive cooling, overload protection, and can withstand temperature extremes from -4 to 158°F.
Provides up to 60 watts (24 V, 2.5 A) of power for PoE devices such as switches, network cameras, and access points.
Overload/short circuit/over voltage protection
This power supply undergoes a 100% full-load burn-in test
Cooling by free air convection
Metal enclosure with integrated DIN-rail mount
Rated for an operating temperature range of -4 to 158°F
Certified for UL 508, UL 60950-1, TUV EN60950-1, and Class I, Div. 2 Group A, B, C, D hazardous locations T4
Compliance to EN55011, EN55022 (CISPR22), EN61204-3 Class B, EN61000-3-2/3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, EN61000-6-2, EN61204-3, heavy industry level, and criteria A
Rated for vibration (IEC 60068-2-6)
LED indicator confirms power to the unit
DC OK relay contact
Short circuit/overload/over voltage protection
Protection type: shut down and repower
UPC: 710931160376
In the Box
- TRENDnet TI-M6024 60W Single Output Industrial DIN-Rail Power Supply
- Limited 1-Year Manufacturer Warranty
TRENDnet TI-M6024 Specs
| Interface |
Input: 100-240 VAC, 50/60 Hz, 1.8 A 120-370 V DC
Output: 60 Watts, 24 V, 2.5 A DIN rail: TS-35/7.5 or 15 |
| Housing |
Metal case
DIN-rail mount LED indicator confirms power to the unit |
| Temperature & Humidity |
Operating Temperature
-4 to 158°F / -20 to 70°C Operating Humidity Max. 90% non-condensing |
| MTBF |
2,992,000 hours
|
| Certifications |
CE
UL 508 UL 60950-1 CB 60950-1 TUV EN60950-1 Class I, Div. 2 hazardous locations T4 |
| Dimensions |
1.6 x 3.9 x 3.5" / 40 x 100 x 90 mm
|
| Weight |
10.6 oz / 300 g
|
Packaging Info
| Package Weight |
0.7 lb
|
| Box Dimensions (LxWxH) |
4.6 x 4.2 x 1.8"
|
