Description
- Unmanaged Ethernet Switch
- 24x Gigabit Ethernet Ports
- GREENnet Power Saving Technology
- Plug-and-Play
- Housed in a Sturdy Metal Enclosure
- Windows, Mac, Linux Compatible
The TEG-S24g 24-Port Gigabit GREENnet Switch from Trendnet is an easy-to-use, high-speed, power-efficient solution for connecting different Ethernet-enabled devices on your network. This switch features twenty-four Gigabit Ethernet ports that are also Auto-MDIX. With Auto-MDIX, you can connect either a regular or crossover cable to a port and the switch will adjust no matter the cable type. You can also use standard Ethernet cables as crossover cables when connecting devices. Since this switch is plug-and-play, you can start using it as soon as you connect Ethernet-enabled network devices. No need to configure it. The diagnostic LEDs will let you know when connections are established.
Because this switch is designed with GREENnet technology, it can reduce its power consumption by 70% in comparison to standard Trendnet switches. It reduces its power consumption when an Ethernet port is not in use, when an Ethernet cable is a shorter length, when a connected device is in power saving mode, and when a connected device is turned off. Housed in a sturdy metal enclosure, this switch is an easy, energy-efficient, high-speed way to connect up to twenty-four devices on your network.
- Twenty four 10/100/1000Mbps Auto-MDIX Gigabit Ethernet ports
- On / off power switch
- Features a 48Gbps forwarding capacity
- Internal power supply reduces clutter
- GREENnet technology reduces electrical power consumption for the following scenarios:
1. Ethernet port is not in use
2. Connected device is turned off
3. Connected device is in power-saving mode
4. Based on Ethernet cable length
- IEEE 802.3x Flow Control for full-duplex mode
- Back pressure Flow Control for half-duplex mode
- Store-and-Forward switching architecture with non-blocking wire-speed performance
- Integrated address look-up engine with an 8K MAC address table
- 3.5MBits RAM data buffer
- Operates and maximizes packet filtering and forwarding rate
- Rackmount hardware included
- Jumbo Frame support up to 9216Bytes
- Sturdy metal housing
- Diagnostic LEDs and Plug & Play support
- 3-year limited warranty
| Performance | |
|---|---|
| Standards | IEEE 802.3 10Base-T; IEEE 802.3u 100Base-TX IEEE 802.3ab 1000 Base-T; IEEE 802.3x Flow Control |
| Protocols | CSMA/CD, Star |
| Interface | 24x 10/100/1000 Mbps Auto-MDIX RJ-45 ports |
| Speed | Ethernet: 10Mbps/20Mbps (half/full-duplex) Fast Ethernet: 100Mbps/200Mbps (half/full-duplex) Gigabit Ethernet: 2000Mbps (full-duplex) |
| Network | Network Media Ethernet: Cat. 5 up to 100 m Fast Ethernet: Cat. 5 and 5e up to 100 m Gigabit Ethernet: Cat. 5e and 6 up to 100 m |
| MAC Address Table Size | 8K entries |
| RAM Buffer | 3.5Mbps |
| Frame Support | 9216 Bytes |
| LEDs | Diagnostic: Power Link/ACT 100Mbps 1000Mbps |
| Certifications | FCC, CE |
| RoHS Compliant | Yes |
| General | |
|---|---|
| Operating System | Windows, Mac, and Linux compatible |
| Environmental Requirements | Temperature Operating: 32° to 104°F / 0° to 40°C Storage: 14° to 158°F / -10° to 70°C Humidity Max: Up to 90% (non-condensation) |
| Power Requirements | 100 to 240VAC, 50/60Hz Internal universal switching power |
| Power Consumption | Up to 13 Watts |
| Dimensions | 11 x 7 x 1.7" / 28 x 18 x 4.4 cm |
| Weight | 3.8 lb / 1.7kg |
| Packaging Info | |
|---|---|
| Package Weight | 7.3 lb |
| Box Dimensions (LxWxH) | 22.0 x 12.3 x 3.8" |
- Multi-Language Quick Installation Guide
- 6' / 1.8 m Power Cord
- Rackmount Hardware
- 3-Year Limited Warranty
