Description
TRENDnet TEG-204WS Overview
- 1Description
- 2Web Smart Management
- 3Integration Flexibility
- 4High-Speed SFP
- 5Hardware Design
- 6IPv6 Ready
- 7Traffic Management
- 8Troubleshooting
- 9Access Control
- 10Monitoring
With a 40 Gbps switching capacity and a variety of advanced management features, the TEG-204WS 20-Port Gigabit Managed Switch from TRENDnet gives network admins complete control over their network. This switch comes equipped with 16 Gigabit ports and 4 shared Gigabit ports (RJ45/SFP), making it easy to connect a variety of network components directly to the switch. The switch can be easily installed into an existing rack and features a fanless metal housing.
Once installed, network admins can utilize features like 802.3ad link aggregation, asymmetric VLAN, 802.1Q VLAN, Voice VLAN, Loopback Detection, and much more to easily manage traffic throughout the network. Monitoring protocols including RMON, SNMP, SNMP Trap, and Port Mirroring also provide admins the ability to manage various aspects of the network. If that's not enough, access control features including ACL, SSL, MAC/port filtering, and a variety of additional protocols offer enhanced access control capabilities.
Web Smart Management
Provides an easy-to-use web-based GUI management for reduced switch configuration complexity and offers a combination of SMB management features for easy deployment.
Integration Flexibility
Managed features include access control lists, VLAN, IGMP snooping, QoS, RMON, SNMP trap, and syslog for monitoring and flexible network integration.
High-Speed SFP
Offers four shared gigabit SFP slots to allow for long distance fiber optic connections.
Hardware Design
Fanless rack mountable 1U metal housing features 16 gigabit ports and 4 shared gigabit ports (RJ-45/SFP).
IPv6 Ready
This switch supports IPv6 configuration and IPv6 neighbor discovery.
Traffic Management
A broad range of network configurations are supported by: 802.3ad link aggregation, Asymmetric VLAN, 802.1Q VLAN, Voice VLAN, RSTP, MSTP, Loopback Detection, GVRP, 802.1p Class of Service (CoS), port bandwidth management, and QoS queue scheduling.
Troubleshooting
A convenient cable diagnostic test and traffic statistics aid in network troubleshooting.
Access Control
Features such as ACL, SSL, MAC/port filtering, 802.1X, TACACS+, and RADIUS are compatible with layered access controls.
Monitoring
RMON, SNMP, SNMP Trap, and Port Mirroring support administrator monitoring solutions.
UPC: 710931140392
In the Box
- TRENDnet TEG-204WS 20-Port Gigabit Managed Switch
- Power Cord
- Rack Mount Kit
- Limited Lifetime Manufacturer Warranty
Table of Contents
- Description
- Web Smart Management
- Integration Flexibility
- High-Speed SFP
- Hardware Design
- IPv6 Ready
- Traffic Management
- Troubleshooting
- Access Control
- Monitoring
TRENDnet TEG-204WS Specs
| Standards | IEEE 802.1d IEEE 802.1p IEEE 802.1Q IEEE 802.1s IEEE 802.1w IEEE 802.1X IEEE 802.1ab IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3z IEEE 802.3ab IEEE 802.3ad IEEE 802.3az |
| Device Interface | 16 x Gigabit ports 4 x shared Gigabit ports (RJ-45/SFP) LED indicators |
| Data Transfer Rate | Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex) Gigabit Ethernet: 2000 Mbps (full duplex) |
| Performance | Switch Fabric: 40 Gbps RAM Buffer: 512 KB MAC Address Table: 8 K entries Jumbo Frames: 10 KB HOL Blocking Prevention Forwarding Rate: 29.8 Mpps (64-byte packet size) |
| Management | HTTP/HTTPS (SSL v2/3 TLS) Web based GUI SNMP v1, v2c, v3 RMON v1 Static Unicast MAC Address Enable/disable 802.3az Power Saving LLDP and LLDP-MED Virtual Cable Diagnostics Test IPv6: IPv6 Neighbor Discovery, IPv6 Static IP, DHCPv6, Auto configuration |
| MIB | IP FORWARD TABLE MIB RFC 1354 RMON MIB RFC 1271 IPV4 MIB RFC 1213 IPV6 MIB RFC 2465 GVRP MIB IEEE 802.1Q-VLAN LA MIB IEEE 802.3ad LLDP MIB IEEE 802.1AB IGMP SNOOPING MIB RFC 2933 MLD SNOOPING MIB RFC 3019 PRIVATE VLAN MIB IEEE 802.1Q DHCPSNOOP MIB RFC 2026 QOS MIB RFC 4323 SNMP MIB RFC 3415 STP MIB RFC 4318 PNAC MIB IEEE 802.1x VLAN MIB IEEE 802.1q DNS MIB RFC 1611 ACL MIB BANDWIDTH CTRL MIB LBD MIB MIRROR MIB IPV6 NEIGHBOR MIB SNTP MIB STORM CTRL MIB STATISTICS MIB Tool MIB VOICE VLAN MIB DOS MIB |
| Spanning Tree | IEEE 802.1D STP (Spanning Tree Protocol) IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) IEEE 802.1s MSTP (Multiple Spanning Tree Protocol) |
| Link Aggregation | Static Link Aggregation 802.3ad Dynamic LACP |
| Quality of Service (QoS) | 802.1p Class of Service (CoS) DSCP (Differentiated Services Code Point) Bandwidth Control per port Queue Scheduling: Strict Priority, Weighted Round Robin (WRR) |
| VLAN | Multiple management VLAN assignment Asymmetric VLAN 802.1Q Tagged VLAN Dynamic GVRP Up to 256 VLAN groups, ID Range 1-4094 Private VLAN (Protected Ports) Voice VLAN (10 user defined OUIs) |
| Multicast | IGMP Snooping v1, v2, v3 (per VLAN) Static Multicast Address Up to 256 multicast entries |
| Port Mirroring | RX, TX, or Both One to one |
| Encryption | 802.1X Port-Based Network Access Control, RADIUS, TACACS+ Local Dial-In User Authentication DHCP Snooping (per VLAN) Loopback Detection Duplicated Address Detection Trusted Host Denial of Service (DoS) |
| ACL | ACL IPv4 L2-L4 & IPv6 MAC Address VLAN ID Ether Type (IPv4 only) IP Protocol 0-255 TCP/UDP Port 1-65535 802.1p DSCP (IPv4 only) IPv6 Address (IPv6 only) |
| Compatibility | Optional Software Utility: Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server |
| Power | Input: 100 - 240 VAC, 50/60 Hz, internal power supply Consumption: 14.6 W (max.) |
| MTBF | 836,517 hours |
| Temperature & Humidity | Operating Temperature 23 to 122°F / -5 to 50°C Operating Humidity Max. 95% non-condensing |
| Certifications | CE, FCC, UL |
| Dimensions | 11.00 x 7.00 x 1.74" / 280 x 180 x 44 mm |
| Weight | 3.88 lb / 1.76 kg |
Packaging Info
| Package Weight | 5.9 lb |
| Box Dimensions (LxWxH) | 13.858 x 13.071 x 2.677" |
