Description
The TSRN 1-24150 is a 1-output Switching Regulator with wide input voltage range. The TSRN-1 series step-down switching regulator is drop-in replacement for inefficient 78xx linear regulator. The TSRN-1 switching regulator provide other significant features over linear regulators, i.e. better output accuracy (�2%), lower standby current of 2mA and no requirement of external capacitors. The high efficiency and low standby power consumption makes this regulator an ideal solution for many battery powered applications.
- Suitable for positive and negative output circuit
- Pin compatible with LMxx linear regulators
- Built-in filter capacitors
- No heat-sink required
- Over-temperature protection
- Short-circuit protection
- Excellent line/load regulation
- Low standby current
- -40 to +85�C Operating temperature range
Applications
Power Management
Product details
| Output Power Max | - |
| Input Voltage DC Min | 16.5V |
| DC / DC Converter Mounting | Through Hole |
| Product Range | - |
| Output Current Max | 1A |
| Approvals & Standards | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Output Voltage Nom. | 15V |
| Input Voltage DC Max | 42V |
Other details
| Brand | TRACOPOWER |
| Part Number | TSRN 1-24150 |
| Quantity | Each |
| Technical Data Sheet EN |  |
