Description
The TSM 0505S from Tracopower is a single output, isolated, 1W DC to DC converter in SOIC-14 pin package. This device can be soldered without any problems in a high temperature lead free solder process. Its small footprint is an economical solution for point of load power conversion, ground loop elimination, noise reduction and digital interface applications.
- Input voltage is 5VDC
- Output voltage is 5VDC
- Output current is 200mA
- Typical efficiency is 80%
- I/O isolation is 1KVDC
- Operating temperature range from -40�C to 85�C
- Reflow solder temperature up to 245�C
- Dimension is 8mm x 6.8mm x 12.7mm (D x H x W)
- High accuracy of pin co-planarity
Applications
Industrial, Power Management
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 4.5V |
| DC / DC Converter Mounting | Surface Mount Device |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 8mm |
| Width | 12.7mm |
| Product Range | TSM Series |
| DC / DC Converter Type | Surface Mount DIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 5.5V |
| Output Current - Output 1 | 200mA |
| Height | 6.8mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TSM 0505S |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
