Description
The TMR 3-2423 is a 2-output board-mount isolated DC to DC Converter with fully regulated output voltage and wide 2:1 input voltage range. The TMR-3 series 3W isolated DC/DC converter comes with a small footprint and excellent efficiency. The compact dimensions of this converter make it an ideal solution for many space critical applications.
- 1500VDC I/O Isolation
- High efficiency up to 85%
- Short-circuit protection
- Remote on/off control
- -40 to +85°C Operating temperature range
Applications
Power Management, Communications & Networking, Industrial
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 100mA |
| Depth | 21.8mm |
| Width | 9.2mm |
| Product Range | TMR 3 Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 100mA |
| Height | 11.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 3-2423 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 3058.18 |
| 3-5 | ₹ 3026.97 |
| 5-10 | ₹ 2964.56 |
| 10+ | ₹ 2902.15 |
Bulk discount will be automatically applied during checkout based on quantity.
