Description
This is a Isolated Board Mount DC/DC Converter, 1 Output, 3 W, 9 V, 333 mA product from TRACOPOWER with the model number TMR 3-2419WIR
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 3W |
| Output Voltage - Output 1 | 9V |
| Output Current - Output 1 | 333mA |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | TMR 3WIR Series |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Width | 9.6mm |
| Height | 11.2mm |
| Depth | 21.8mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 3-2419WIR |
| Quantity | Each |
| Technical Data Sheet EN |  |
