Description
The TMR 3-2411 is a 1-output board-mount Isolated DC/DC Converter. A high efficiency allows a wide operating temperature range of -40 to +85�C. It requires only 2cm� board space.
- Wide 2:1 input range
- 82% Efficiency
- 1500VDC I/O isolation
- �0.02%/K Temperature coefficient
- 3300�F Maximum capacitive load
- 100kHz Switching frequency
- Fully regulated output voltage
- Remote ON/OFF control
Applications
Power Management, Communications & Networking, Sensing & Instrumentation, Industrial
Product details
| Output Power Max | 3W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 21.8mm |
| Width | 9.2mm |
| Product Range | TMR 3 Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 600mA |
| Height | 11.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 3-2411 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
