Description
The TMR 2411 from Tracopower is a single output, isolated, 2W DC to DC converter with SIP-8 package. This module provides regulated output, featuring wide 2:1 input voltage range with small footprint occupying only 2cm² of board space as they offer the ideal solution in many space critical applications for board level power distribution. It functions with remote On/Off control and continuous short circuit protection. The ultra compact dimensions of these converters make them an ideal solution for many space critical applications.
- Input voltage range from 18VDC to 36VDC
- Output voltage is 5VDC
- Output current is 400mA
- Typical efficiency is 81%
- I/O isolation is 1KVDC
- Operating temperature range from -40°C to 85°C
- Dimension is 21.8mm x 11.1mm x 9.2mm (D x H x W)
- Excellent load and line regulation
- High efficiency
- UL/cUL 60950-1, IEC/EN 60950-1 safety standards certified
Applications
Industrial, Power Management
Product details
| Output Power Max | 2W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 21.8mm |
| Width | 9.2mm |
| Product Range | - |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 400mA |
| Height | 11.1mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 2411 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
