Description
The TMR 2-4811WI is a 1-output board-mount isolated DC to DC Converter with regulated output voltage and ultra wide 4:1 input voltage range. The TMR-2WI series 2W DC/DC converter comes with an excellent efficiency. This ultra-compact converter is ideal for battery operated equipment application and everywhere where space on the PCB is critical.
- Full SMD design
- High efficiency
- Excellent load and line regulation
- 1500VDC I/O Isolation
- Remote on/off control
- -40 to +85�C Operating temperature range
Applications
Power Management, Communications & Networking, Industrial
Product details
| Output Power Max | 2W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 26mm |
| Width | 9.3mm |
| Product Range | TMR2WI Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 75V |
| Output Current - Output 1 | 400mA |
| Height | 12.5mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 2-4811WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
