Description
This is a Isolated Board Mount DC/DC Converter, 2 Output, 2 W, 5 V, 200 mA, -5 V, 200 mA product from TRACOPOWER with the model number TMR 2-2421WIN
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 2W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 200mA |
| Output Voltage - Output 2 | -5V |
| Output Current - Output 2 | 200mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | TMR 2WIN Series |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | CAN, CSA, IEC, UL |
| Width | 9.3mm |
| Height | 11.2mm |
| Depth | 21.8mm |
| RoHS Phthalates Compliant | Yes |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 2-2421WIN |
| Quantity | Each |
| Technical Data Sheet EN |  |
