| ₹ 1414.6 includes GST and import duties. | |
| B2B customers can avail ₹ 215.73 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Isolated Board Mount DC/DC Converter, Regulated, Through Hole, 1W, 12V, 42mA, -12V, 42mA product from TRACOPOWER with the model number TMR 1-1222
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 9V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -12V |
| Output Current - Output 2 | 42mA |
| Depth | 17mm |
| Width | 7.62mm |
| Product Range | TMR 1 & TMR 1SM Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| No. of Outputs | 2 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 18V |
| Output Current - Output 1 | 42mA |
| Height | 11mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TMR 1-1222 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1386.31 |
| 3-5 | ₹ 1372.16 |
| 5-10 | ₹ 1343.87 |
| 10+ | ₹ 1315.58 |
Bulk discount will be automatically applied during checkout based on quantity.
