Description
The TIW 24-124 is a 24V/24W DC Power Supply with fully encapsulated plastic housing, which has been designed particularly for applications in home and office installations. The compact modules cases fit in the standardized in-wall flush boxes. The TIW-series is a new range of small size, connection there are models available with flying wires. The power supplies comply fully with the safety and EMC standards requested for commercial and residential class-II installations. Typical applications are powering of electric devices used in home automation and in security systems like i.e. DC-motors, controllers, indicators, etc.
- Universal input
- High efficiency
- Easy installation into standard flush box
- Dust-proof and waterproof to IP67
- Protection class-II
- -25 to 50�C Operating temperature range
Applications
Building Automation, Security, Motor Drive & Control, Automation & Process Control, Commercial
Product details
| Power Supply Output Type | Fixed |
| Output Power Max | 24W |
| No. of Outputs | 1Outputs |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Input Voltage AC Max | 264V |
| Input Voltage AC Min | 93V |
| Product Range | TIW Series |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 24V |
| Output Current - Output 3 | - |
| Output Current - Output 4 | - |
| Output Voltage - Output 4 | - |
| Output Current - Output 1 | 1A |
Other details
| Brand | TRACOPOWER |
| Part Number | TIW 24-124 |
| Quantity | Each |
| Technical Data Sheet EN |  |
