Description
This is a Isolated Board Mount DC/DC Converter, Metal Case, 1 Output, 30 W, 12 V, 2.5 A product from TRACOPOWER with the model number THN 30-4812WI
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 30W |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 1 | 2.5A |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | THN 30WI Series |
| Input Voltage DC Min | 18V |
| Input Voltage DC Max | 75V |
| DC / DC Converter Output Type | Fixed, Adjustable |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 25.4mm |
| Height | 9.9mm |
| Depth | 25.4mm |
Other details
| Brand | TRACOPOWER |
| Part Number | THN 30-4812WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Application Note EN | |
